VT101C
1.Screen Size: 10.1 inch
2.Dimension (W x H x T): 235.0 x 143.0 x 5.0 mm
3.Active Area: 222.72 x 125.28 mm
4.Resolution: 1024x(RGB)x600 (pixels)
5.View angle (U/D/L/R): 45/60/60/60
6.Brightness:350 cd/m2
7.Contrast Ratio:500:1
8.Interface: LVDS interface
Pin Symbol Pin Symbol Pin Symbol
1 VCOM 21 RXIN3+
2 VDD 22 GND
3 VDD 23 NC
4 NC 24 NC
5 RESET 25 GND
6 STBYB 26 NC
7 GND 27 DIMO
8 RXIN0- 28 SELB
9 RXIN0+ 29 AVDD
10 GND 30 GND
11 RXIN1- 31 LED -
12 RXIN1+ 32 LED -
13 GND 33 L/R
14 RXIN2- 34 U/D
15 RXIN2+ 35 VGL
16 GND 36 CABCEN1
17 RXCLKIN- 37 CABCEN0
18 RXCLKIN+ 38 VGL
19 GND 39 LED +
20 RXIN3- 40 LED +
